DIGITAL MULTIMETER DT4261

Analyzing Issues in the Field and Dramatically Improving Work Efficiency

  • Option
  • When Z3210 is installed

Product video

Hioki mid-range DMM, the DT4261, is an exceptional support tool with multifaceted functionality designed to help analyze a variety of issues and boost work efficiency.

CAT III 1000 V, CAT IV 600 V

Key Features

  • Helping personnel analyze issues in the field
  • Boost work efficiency with digitalization (Excel® Direct Input Function)
  • Ensuring safety by preventing erroneous test lead insertion (terminal shutters)
  • Stop worrying about losing test lead caps
  • Excellent dust and water resistance (compliant with the IP54 international standard)

Model No. (Order Code)

DT4261 Wireless Adapter Z3210 not included
DT4261-90 Bundled with the Wireless Adapter Z3210

Data can be downloaded to tablets and smartphones using Hioki’s dedicated free app "GENNECT Cross," available from the Google Play or App Store.

Safe inspection of solar installations with high voltage

DC High V Probe Mode

- Enables high voltage measurement up to CAT III 2000 V
- Safely measure solar installations like the mega-solar without interrupting the grid by simply connecting the DC High Voltage Probe P2000 to compatible Hioki clamp meters and digital multimeters (DMMs)

See details about DC High Voltage Probe P2000

Helping personnel analyze issues in the field

Harmonic measurement

When combined with GENNECT Cross (*1), you can perform simple harmonic analysis. Applications include harmonic measurement of power conditioners for solar systems and problem analysis of power supply systems.

See here for details about GENNECT Cross

Problems that can be caused by harmonics

  • Equipment burn-out and destruction due to overheating
  • Malfunctions of power control devices
  • Increased loss along with reduced service life and efficiency for power devices
  • *1:GENNECT Cross is an free app that lets you connect field measuring instruments to smartphones and tablets using Bluetooth® communications. Wireless Adapter Z3210 (sold separately) is required in order to pair the DT4261 with GENNECT Cross.

Wireless communication capability for even greater convenience

Wireless support

When the Wireless Adapter Z3210 is installed, Bluetooth® wireless communication is enabled. It transfers measurements to your smartphone or tablet and allows you to quickly create reports with field photos and drawings.

See details about Wireless Adapter Z3210

Excel® Direct Input Function (*2)

Boost work efficiency in the field by letting you directly transfer measurement data to (i.e., enter measured values directly into) templates created as Excel®.

  • *2:The optional Wireless Adapter Z3210 is required.

Prevents incorrect current measurement

Fuse check function

When switching from the clamp function to the current function, a fuse disconnection check is automatically performed.
This allows the user to know if the fuse is broken before current measurement, which prevents erroneous measurement.

Ensuring safety by preventing erroneous test lead insertion

Terminal shutters

Due to the current terminal’s low impedance, measuring voltage after erroneously inserting a test lead into the current terminal will cause the fuse to blow. The DT4261’s terminal shutters are linked to the instrument’s rotary switch such that they block access to test lead terminals that aren’t being used, making it physically impossible to insert a lead into the wrong terminal.

More recommended features

Stop worrying about losing test lead caps

Test Lead L9300 incorporate integrated caps for greater convenience and safety. The design lets you change the measurement category simply by sliding the test lead’s protective finger guard. You no longer have to worry about losing caps!

3D View

Multifaceted functionality and performance for a variety of tasks

  • Ability to withstand being dropped onto concrete from a height of 1 m (drop-proof design)

  • Broad operating temperature range of -25°C to 65°C
  • Automatic detection of DC and AC voltages (AUTO V function)
  • Visual warning of excessive input via red backlight
  • Visual indication of HOLD operation via orange light

Basic specifications

Accuracy guaranteed: 1 year
DMM Accuracy: Due to the many ranges and functions available in a DMM, only the basic accuracy is indicated for reference. Please refer to the brochure for detailed accuracy information.
DC Voltage range 600.0 mV to 1000 V, 5 ranges, Basic accuracy: ±0.15% rdg. ±2 dgt.
AC Voltage range 6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz to 1 kHz
Basic accuracy 40 Hz - 500 Hz: ±0.9% rdg. ±3 dgt. (True RMS, crest factor 3 or less)
DC + AC Voltage range 6.000 V to 1000 V, 4 ranges, Frequency characteristics: DC, 40 Hz to 1 kHz
Basic accuracy DC, 40 Hz - 500 Hz: ±1.0% rdg. ±13 dgt. (True RMS, crest factor 3 or less)
LoZ V 600.0 V, 1 range, Frequency characteristics: DC, 40 Hz to 1 kHz
Basic accuracy DC, 40 Hz - 500 Hz: ±1.0% rdg. ±13 dgt. (True RMS, crest factor 3 or less)
Resistance range 600.0 Ω to 60.00 MΩ, 6 ranges, Basic accuracy: ±0.7% rdg. ±3 dgt.
DC Current range 600.0 mA to 10.00 A, 3 ranges
Basic accuracy: ±0.5% rdg. ±3 dgt.
AC Current range 600.0 mA to 10.00 A, 3 ranges
Basic accuracy 40 Hz - 500 Hz: ±1.4% rdg. ±3 dgt. (True RMS, crest factor 3 or less)
Frequency characteristics: 40 Hz to 1 kHz
AC Current range (use with Clamp on probes) 10.00 A to 1000 A, 7 ranges
Basic accuracy 40 Hz - 500 Hz: Add the Clamp on probe accuracy to ±0.9% rdg. ±3 dgt.
(True RMS, crest factor 3 or less)
Capacitance range 1.000 μF to 10.00 mF, 5 ranges, Basic accuracy: ±1.9% rdg. ±5 dgt.
Continuity Check Continuity threshold ON : 25 Ω, Continuity threshold OFF : 245 Ω, Response time: 0.5 ms or more
Diode test Open terminal voltage: 2.0 V or less, Testing current: 0.2 mA or less, Threshold of forward voltage: 0.15 V to 1.8 V
Voltage frequency range 99.99 Hz to 99.99 kHz, 4 ranges (Limited by minimum sensitivity voltage)
Basic accuracy: ±0.1% rdg. ±1 dgt.
Current frequency range 99.99 Hz to 9.999 kHz, 3 ranges (Limited by minimum sensitivity current)
Basic accuracy: ±0.1% rdg. ±1 dgt.
Harmonic levels [With Z3210 installed] Voltage/Current harmonic levels up to 30th, Content factor, Total harmonic distortion ratio
*Harmonics can be displayed with our free app GENNECT Cross.
Other functions Mis-insertion prevention shutters, fuse check function, user setting retention function, filter function, zero-adjustment, display value hold, auto hold, MAX/MIN value display, PEAK value display, auto-power save, USB communication (when optional Communication Package DT4900-01 is installed), wireless communication (when optional Wireless Adapter Z3210 is installed)
Display Main and sub displays: 4-digits LCD, max. 6000 digits (excluding frequency measurement), bar-graph
Display refresh rates 5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 times/s)
Power supply LR6 (AA) alkaline batteries × 3, Continuous operating time: 130 hr. (without Z3210 installed), 70 hr. (with Z3210 installed and using wireless communications)
Dimensions and mass 87 mm (3.43 in.) W × 185 mm (7.28 in.) H × 47 mm (1.85 in.) D, 480 g (16.9 oz.) (with test leads holder and batteries)
Included accessories Test Lead L9300 × 1, Instruction Manual × 1, LR6 (AA) alkaline battery × 3, Operating Precautions ×1

Test leads (3)

TEST LEAD L9207-10

Cable length: 90 cm (2.95 ft.)

TEST LEAD L9300

Cable length 95 cm (37.4 in.), Integrated cap and protective finger guard

DC HIGH VOLTAGE PROBE P2000

Learn more

• Safe inspection of solar installations with high voltage
• Enables high voltage measurement up to CAT Ⅲ 2000 V

Options for Test leads (for the L9207-10, L9300) (2)

Attach L9207-10 with the cap removed.
Slide the guard of L9300 and attach as measurement category II.

CONTACT PIN SET L4933

Attaches to the tip of the Test Lead L9207-10/DT4911, L9206, 60V DC/ 30V AC

SMALL ALLIGATOR CLIP SET L4934

Attaches to the tip of the L4932, L9207-10/DT4911, L9206, CAT III 300 V, CAT II 600 V

Options for Test leads (for the L4930) (10)

CONNECTION CABLE SET L4930

1.2 m (3.94 ft) length, CAT IV 600 V, CAT III 1000 V

EXTENSION CABLE SET L4931

Expands the length of L4930/4940, 1.5 m (4.92 ft) length

TEST PIN SET L4932

Attaches to the tip of the L4930/4940, CAT IV 600 V, CAT III 1000 V

ALLIGATOR CLIP SET L4935

Attaches to the tip of the L4930/4940, CAT IV 600 V, CAT III 1000 V

BUS BAR CLIP SET L4936

Attaches to the tip of the L4930/4940, CAT III 600 V

MAGNETIC ADAPTER SET L4937

Attaches to the tip of the L4930/4940, CAT III 1000 V

TEST PIN SET L4938

Attaches to the tip of the L4930/4940, CAT III 600 V

BREAKER PIN SET L4939

Attaches to the tip of the L4930/4940, CAT III 600 V

GRABBER CLIP L9243

Attaches to the tip of the banana plug cable, Red/Black: 1 each, 185 mm (7.28 in.) length, CAT II 1000 V

MAGNETIC ADAPTER 9804

Attaches to the tip of voltage cord, φ11 mm (0.43 in), compatible M6 pan screws

Current measurement (4)

CLAMP ON PROBE 9010-50

Learn more

• 40 Hz to 1 kHz, ±2% accuracy
• 10 to 500 A AC
• Max. 650 A rms continuous input
CLAMP ON PROBE 9018-50

Learn more

• 40 Hz to 3 kHz, ±1.5% accuracy
• 10 to 500A AC
• Max. 650 A rms continuous input
CLAMP ON PROBE 9132-50

Learn more

• 40 Hz to 1 kHz, ±3% accuracy
• 20 to 1000A AC
CONVERSION ADAPTER 9704

Receiving side BNC (female), output banana (male) *Not compatible with older generation Memory Hicorders with banana input terminals

Communication (2)

COMMUNICATION PACKAGE (USB) DT4900-01

Compatible to Windows 10

WIRELESS ADAPTER Z3210

Learn more

• Increase your work efficiency, by eliminating human errors from manual reporting
• Transfer readings on instruments to easy-to-read graphical reports to prove integrity
• Compliance with wireless regulations in more than 50 countries and regions

Carrying case (2)

CARRYING CASE C0202

CARRYING CASE C0207

Bag type

Strap (2)

MAGNETIC STRAP Z5004

MAGNETIC STRAP Z5020

Extra strength

Connect to your smartphone or tablet (1)

When using the Z3210

GENNECT CROSS SF4071, SF4072

Learn more

• Mobile app for iOS, Android
• Improve efficiency of operations that repeat measurement and recording
• Analyze correlated data during issues and generate quick reports
