DIGITAL MULTIMETER

DT4254

Digital Multimeter for Efficiently Maintaining Power Equipment, PV and Megasolar Devices

The Hioki DT4200 Digital Multimeter Series consist of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super fast response rate and safety features that take electrical testing to a higher level. The DT4254 is a voltage measurement only model designed for measuring photovoltaic modules and other high-voltage targets up to 1700 V DC (*1). CAT IV 600 V, CAT III 1000 V Key Features • The voltage measurement model, which is ideal for solar power system and power equipment management, measures up to 1700 V DC (*1) during open voltage inspections (DT4254) • Prevents accidents with clamp-on sensor-based current measurement (DT4254, DT4255) • Voltage detection function (DT4254, DT4255) • Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms) • Broad -25°C (-13°F) to 65°C (149°F) operating temperature range (DT4254, DT4255) • Dual display lets you check voltage and frequency simultaneously *1 Your instrument can be used to measure voltages in excess of 1000 V DC if and only if both of the following conditions are satisfied: 1. The circuit under measurement is isolated from the commercial power grid. 2. The circuit under measurement is isolated from ground.



Model No. (Order Code)

DT4254 Voltage measurement only

GOOD DESIGN
Guarantee3years
USB2
Option
TrueRMS
CE
DROPPROOF

Video on how to use digital multimeters

This video introduces how to use the DT4200 series of digital testers as well as some of the instrument’s featured functionality. Hioki testers are engineered to help professional electricians do their jobs safely and quickly.


High-voltage measurement digital multimeter that measure up to 1700 V

The DT4254, which is part of Hioki’s DT4250 series of standard digital multimeters, is ideal for measuring photovoltaic modules and other high-voltage targets at up to 1700 V DC. ・ DC current 600.0mV / 6.000V / 60.00V / 600.0V / 1000V / 1500V ・ Voltage detection function


Test no-load voltage at megasolar installations

The DT4254 can measure DC voltages up to 1700 V, enabling you to make no-load voltage inspections of megasolar installations.


Polarity detection and notification

The DT4254 can detect a load voltage in excess of -10 V and notify the operator with a red LED and beep. This feature helps prevent recording of erroneous measured values.


Measure output voltage on the secondary sides of inverters by eliminating harmonic components

Accurately measure the fundamental wave alone by eliminating harmonic components with the DMM’s low-pass filter function.


Measurement data can be downloaded to, reviewed on, and saved to a computer.

If you connect the DT4254 to a computer with the optional Communication Package DT4900-01, you can graph data stored in the instrument’s internal memory and display measurement results in real time on the computer. In addition, displayed measured values can be saved (in text format).  *The computer and multimeter are electrically isolated by means of optical communications so that data can be sent without concern for electrical hazards.


True RMS measurement for accurate measurement of even distorted current waveforms

Digital multimeters implement two types of measurement: mean-value measurement and true RMS measurement. The two methods yield significantly different measurement results for current waveforms, which are often distorted. For accurate measurement, it is necessary to use an instrument with true RMS capability.


Designed and manufactured in Japan to ensure high quality and guaranteed with a 3-year warranty for peace of mind

All development, design, and manufacturing processes for almost all Hioki digital multimeters are carried out at our Head Office in Nagano Prefecture. Some of the industry’s most advanced technological capabilities enable us to deliver products of the highest possible quality.


Safe measurement requires use of an instrument that suits the measurement location.

To ensure operators’ ability to use measuring instruments safely, IEC 61010 classifies the locations in which instruments are used into a series of safety-based measurement categories (ranging from CAT II to CAT IV). Using an instrument that does not satisfy the required safety level can lead to an electrical accident.


Basic specifications (Accuracy guaranteed for 1 year, Post-adjustment accuracy guaranteed for 1 year)Regarding DMM Accuracy Due to the many ranges and functions available in a DMM, only the basic accuracy is indicated for reference. Please refer to the individual catalogs for detailed accuracy information. *1 Your instrument can be used to measure voltages in excess of 1000 V DC if and only if both of the following conditions are satisfied: 1. The circuit under measurement is isolated from the commercial power grid. 2. The circuit under measurement is isolated from ground.

DC Voltage range600.0 mV to 1500 V (*1)
5 ranges, Basic accuracy: ±0.3 % rdg. ±3 dgt.
AC Voltage range6.000 V to 1000 V, 4 ranges, Frequency characteristics: 40 Hz to 1 kHz
Basic accuracy 40 - 500 Hz : ±0.9 % rdg. ±3 dgt. (True RMS, crest factor 3)
AUTO AC/DCVYes
Resistance rangeN/A
DC Current rangeN/A
From 4 to 20mA Percentage conversion displayN/A
AC Current range (use with Clamp on probes)N/A
Temperature (thermocouples)N/A
Voltage detectionHi: AC40 V to 600 V, Lo: AC80 V to 600 V
Capacitance rangeN/A
Frequency range99.99 Hz to 99.99 kHz, 4 ranges (limited by the minimum detectable voltage),
Basic accuracy: ±0.1 % rdg. ±1 dgt.
Continuity checkN/A
Diode testN/A
Other functionsFilter function, Display value hold, Auto hold, Max/Min/Average value display, Relative display, Auto-power save, USB communication (option)
DisplayMain and Sub displays: 4-digits LCD, max. 6000 digits, bar graph
Display refresh rates5 times/s (Capacitance measurement: 0.05 to 5 times/s, depending on measured value, Frequency: 1 to 2 time/s)
Power supplyLR03 alkaline batteries ×4, Continuous use: 130 hours (backlight OFF)
Dimensions and mass84 mm (3.31 in)W × 174 mm (6.85 in)H× 52 mm (2.05 in)D,
390 g (13.8 oz) (including batteries and holster)
AccessoriesTest lead L9207-10 ×1, Holster ×1, Instruction manual ×1, LR03 alkaline battery ×4

Log into your myHioki account to access more technical documents and information where available.

Seminar Videos On Demand

No results were found.

Seminar Schedule

Registration Open

BIXPO 2019 - Gwangju, Korea

Nov 6, 2019 - Nov 8, 2019

Catalogs

Catalog: COMMUNICATION PACKAGE (USB) DT4900-01 Download PDF  [1MB] English
Catalog: DIGITAL MULTIMETER DT4200 Series Download PDF  [8MB] English

User Guides

No results were found.

Manuals

If you can not download, log into your myHioki account to access more technical documents and information where available.


Operating Precautions Japanese
English
Ver.00
Instruction Manual Simplified Chinese
Ver.03
Instruction Manual Korean
Ver.03
Instruction Manual English
Ver.03
Instruction Manual Spanish
Ver.03
Instruction Manual French
Ver.01
Instruction Manual German
Ver.01

Outline Drawings

If you can not download, log into your myHioki account to access more technical documents and information where available.



Ver.01

Drivers, Firmware

DMM Communicator for DT4200s  Freeware Version 2.10

Others

Flyer: Usable temperature range Max.65°C Max.-25°C Download PDF  [1MB] English

Options

Test leads

Options for the L9207-10 (L9207-10 is a bundled accessory)

CONTACT PIN SET L4933

Attaches to the tip of the Test Lead L9207-10/DT4911, L9206, 60V DC/ 30V AC

SMALL ALLIGATOR CLIP SET L4934

Attaches to the tip of the L4932, L9207-10/DT4911, L9206, CAT III 300V, CAT II 600V

TEST LEAD L9207-10

90 cm (2.95 ft) length

Options for Test leads

Options for the L4930

GRABBER CLIP 9243

Attaches to the tip of the banana plug cable, Red/ Black: 1 each, 196 mm (7.72 in) length, CAT III 1000 V

CONNECTION CABLE SET L4930

1.2 m (3.94 ft) length

EXTENSION CABLE SET L4931

Expands the length of the cable with banana plug, 1.5 m (4.92 ft) length

TEST PIN SET L4932

Attaches to the tip of the banana plug cable, CAT IV 600V, CAT III 1000V

SMALL ALLIGATOR CLIP SET L4934

Attaches to the tip of the L4932, L9207-10/DT4911, L9206, CAT III 300V, CAT II 600V

ALLIGATOR CLIP SET L4935

Attaches to the tip of the banana plug cable, CAT IV 600V, CAT III 1000V

BUS BAR CLIP SET L4936

Attaches to the tip of the banana plug cable, CAT III 600V

MAGNETIC ADAPTER SET L4937

Attaches to the tip of the banana plug cable, CAT III 1000V

TEST PIN SET L4938

Attaches to the tip of the banana plug cable, CAT III 600V

BREAKER PIN SET L4939

Attaches to the tip of the banana plug cable, CAT III 600V

Other options

CARRYING CASE 3853

Store with peripherals cable

CARRYING CASE C0201

CARRYING CASE C0202

COMMUNICATION PACKAGE (USB) DT4900-01

For DT4280s/4250s, compatible to Windows 8.1/ 8/ 7/ Vista

MAGNETIC STRAP Z5020

Extra strength
